3 in 1 Handheld Oscilloscope Multimeter with 2 Channels HO52S 3.5"TFT Oscilloscop, 50Mhz Waveform Generator Multimeter Backlit Screen, Auto-Calibration Function, Memory Function, Multi Tester

Descripción

Product description PC Oscilloscope download: dropbox.com/sh/dsyy3oyurlho35x/AABP-Y8FG10KMA1xUQnnOuWFa?dl=0: dropbox.com/sh/dsyy3oyurlho35x/AABP-Y8FG10KMA1xUQnnOuWFa?dl=0 Double sampling mode Peak sampling can be used to detect interference glitches and reduce the possibility of aliasing; High refresh, deep storage Compared with similar handheld oscilloscopes: Waveform refresh rate up to 10000wfms/s, 8K storage depth;easy to capture anomalous events, low probability events; Save function You can save 4 setting groups, 4 reference waveforms, 4 images, and 4 waveform groups in CSV format; The reference waveform can be displayed on the same screen as the measured waveform, which is convenient for waveform comparison;When connected to a computer using the USB TYPE-C interface, the computer recognizes the oscilloscope as a USB flash drive and can read saved images or CSV waveforms;This is useful for later viewing and analyzing waveforms and sharing waveform data; Smart chip, faster charging The LCR features a rechargeable design, high capacity lithium battery and super standby;Supports data recording analysis and computer host computer convenient for remote control and measurement; Multimeter function 20000 reading, 4 1/2 digit true effective value;Supports voltage, current, resistance, capacitance, continuity, and diode measurements; Signal generator Maximum waveform output power can reach 25Mhz;It can output sine waves, square waves, sawtooth waves, pulse waves, and built-in special waveforms. Frequency resolution 0.1Hz;14-bit vertical resolution, 125MSa / S high sampling rate + 8K waveform length;The maximum output amplitude is 5Vpp; USB TYPE-C Rechargeable and Long Lasting Compact handy handheld sized 3.5in LCD display Oscilloscope fits easily in any bag, easy to carry on the go;This portable oscilloscope is equipped with a USB-C charging interface, after every recharge of 2 hours, can be used continuously for a full day or standby more than two months; Handheld oscilloscope It's small, light and easy to carry;You can use it by holding it in your hand; 8 languages Eight languages ​​can be set: Japanese, English, Chinese, French, German, Spanish, Italian, and Russian; HO52S HO52 HO102 H0102S DOS1102 DOS1104 Add to Cart Add to Cart Buying Options Add to Cart Add to Cart Add to Cart Customer Reviews 4.4 out of 5 stars 103 4.7 out of 5 stars 588 4.2 out of 5 stars 84 4.2 out of 5 stars 87 4.4 out of 5 stars 248 4.0 out of 5 stars 88 Price EUR 149.82EUR149.82 EUR 100.45EUR100.45 — no data EUR 201.78EUR201.78 EUR 155.88EUR155.88 EUR 207.84EUR207.84 Oscilloscope function ✓ ✓ ✓ ✓ ✓ ✓ Multimeter function ✓ ✓ ✓ ✓ no data no data Signal generator function ✓ no data no data ✓ no data no data Bandwidth 50MHZ 50MHZ 100MHZ 100MHZ 110MHZ 110MHZ channel 2 channel 2 channel 2 channel 2 channel 2 channel 4channel Acquisition mode Sample, Peak detectSample, Peak detect SSample, Peak detectSample, Peak detect Sample, Peak detectSample, Peak detect Sample, Peak detectSample, Peak detect no data Record Length Max. 8K samples for single-channel, 4K samples per dual-channel Max. 8K samples for single-channel, 4K samples per dual-channel Max. 8K samples for single-channel, 4K samples per dual-channel Max. 8K samples for single-channel, 4K samples per dual-channel no data Size of LCD 3.5 inch HD display 3.5 inch HD display 3.5 inch HD display 3.5 inch HD display 7 inch TFT (True Color) LCD screen 7 inch TFT (True Color) LCD screen Highest real-time sampling rate no data no data no data no data 500MSa/s *2 1GS/s

Características

• ① Oscilloscope mode: 1. The waveform refresh rate is as fast as 10000wfms / s. 2. Dual channel, bandwidth up to 50MHZ, real-time sampling rate of 125MSa / s, record length up to 8k. 3. Cursor measurement function. 4. Four automatic measurement functions. 5. XY function. 6. One-key automatic setting function convenient for testing and debugging.
• ②Multimeter mode: 4 1/2 digits of the actual effective value, digital display: 20000 reading. 1. Standard voltage, current, resistance, diode, continuity, capacitance test. 2. The automatic range function is convenient for testing and debugging. 3. Maximum input voltage is 750VAC and 1000VDC. 4. Independent multimeter and oscilloscope inputs. 5. Read hold function. 6. Relative measurement function.
• ④ The USB Type-C interface supports not only mobile power supply but also adapter charging. With ultra-low power consumption of less than 3W, it can operate continuously for about 6 hours. Supports computer connection. When connected to a computer, the oscilloscope is recognized as a USB flash drive and can read stored images and CSV waveforms, which is convenient for displaying and analyzing future waveforms and sharing waveform data.
• ⑤ Save function: 4 sets of settings, 4 sets of reference waveforms, 4 images and 4 sets of CSV format waveforms. By displaying the reference waveform and the measured waveform on the same screen, it is easy to compare the waveforms. Self-calibration function. Up to 6 automatically measured values ​​can be displayed on the screen at the same time.

Especificaciones
