Pack of 5 DC 0-30V Digital Voltmeter, 3-Wire Voltage Gauge, Blue LED

Descripción

Product description bayite Pack of 5 Three-Wire DC 0~30V Mini Digital Voltmeter, Easy to Calibrate NOTES: When measured voltage is larger than 30V, the voltmeter will be damaged. Main Specifications: Overall Dimension: 23mm x 15mm/0.9" x 0.59", Thickness: 10mm/0.39"Mounting Hole Center Distance: 28mmMeasure Voltage: DC 0~30VWorking Voltage: DC 3V-30VMeasurement Accuracy: 0.01(0.01 - 9.99V) / 0.1(10.0 - 30.0V);Display: Three 0.36" digital LED TubeMeasurement rate: 300mS / timesOperating Temperature: 14 ~ 149 °F(-10 ~ 65 °C)Reverse protection: YesWhen measured voltage is below 10V: the voltmeter displays two decimal digits, for example, 5.32VWhen measured voltage is larger than 10V, the voltmeter displays one decimal digit, for example, 10.5V Wiring: Red wire: Power supply +Black wire: Power supply -, Measured Voltage -White wire: Measured Voltage + Package Includes: 5x DC 0-30V Voltmeter Red Digital Voltmeter DC 4 in 1 Multimeter DC Blue Car Voltmeter DC Red Car Voltmeter Add to Cart Buying Options Add to Cart Buying Options Customer Reviews 4.6 out of 5 stars 662 4.4 out of 5 stars 4,779 4.4 out of 5 stars 441 4.4 out of 5 stars 441 Price $9.99$9.99 $16.19$16.19 $12.99$12.99 — no data High Measurement Accuracy ✓ ✓ ✓ ✓ DC5-120V Mini Voltmeter DC5-120V Mini Voltmeter DC 100A Current Voltage Meter Upgraded DC 100A Volt Amp Meter Add to Cart Add to Cart Add to Cart Buying Options Customer Reviews 4.5 out of 5 stars 210 4.5 out of 5 stars 210 4.5 out of 5 stars 779 4.4 out of 5 stars 345 Price $14.99$14.99 $8.99$8.99 $18.98$18.98 $21.59$21.59 Bright Display ✓ ✓ ✓ ✓ See More

Características

• This is Three-Wire Voltmeter. Three-Wire connection enable the Voltage Test Rang from 0.00 to 30V. (Two-wire meters cannot measure the voltage that is below 3V);
• Measurement Accuracy: 0.01(0.01 - 9.99V) / 0.1(10.0 - 30.0V); And the meter is CALIBRATABLE: The screw on the back is used to Calibrate the meter.
• BRIGHT & NICE Reading: Display: Three 0.36" digital LED Tube; Display Color: BLUE;
• Reverse Polarity Protection: The meter won't burn out if reverse polarity is applied, but the screen will display nothing
• NOTE: When measured voltage is larger than 30V, the voltmeter will be damaged.
