CNCTOPBAOS 3018-PRO CNC Router Engraver Machine w/GRBL Offline Controller

Descripción

Product description Package include: 1Set Upgraded 3 Axis 3018-PRO CNC Router Engraving Milling Machine Kit3x Limit switches (XYZ axis)1x Emergency stop1x GRBL 1.1f Control Board1x GRBL Offline Controller1x 775 spindle motor with ER11 Collet 3.175mm1x 24V DC 5A Power Supply10 x Tip 0.1 mm, 20° φ3.175 mm Drill Bits4x Plate clamps1Set Allen Wrench&ER Wrench1x Brush1x Spindle motor harness 60cm3x Stepper motor harness 60cm1x 4G USB flash drive include the english user manual & GRBL software & Driver & Test filesThe Pdf. user manual is also available for download in the Safety and product resources section of this page. Requires assembly Specification: Working area: 300x180x45mm ( 11.8" x 7.1" x 1.8") Frame size: 420x350x270mm ( 16.53" x13.78" x 10.63")Spindle: 775 100W spindle motor (24V:10000r/min)Processing thickness: 4.5cm (1.8") (height 6.4cm)Material: PA6 nylon & aluminum profileScrew rod: T8 screw rod, lead 4mm, double copper nut to eliminate backlashSpindle Chuck: ER11 Collet (can be equipped with 0-7mm)Step motor: Nema17 stepper motor 34MM,1.33A,0.3N.m,43oz-inPower supply : 24V 5.6A power adapter (input voltage 110-240VAC)Support System: Windows XP SP3,Win 7,Win 8,Win 10 (32/64 can be);LinuxConnection: PC-USB connectionSoftware: GRBL controllerSupporting file: G-code (.nc/.txt/.tape/.gcode)Processing accuracy: about 0.2mm 775 spindle motor Parameters of this 775 spindle : 100W spindle motor (12-36V) 24V:10000rpm/minMounting hole diameter: M4 screw hole; Mounting hole pitch: about 29mm.Spindle PWM speed: Support;power 0-100% adjustableShaft diameter: 15mm;Motor diameter (without magnetic sleeve): 42mmDrill bits: 10pcs tip 0.1mm ,20 degree,diameter3.175mm. Add E-stop & Limit switches The upgraded cnc 3018-PRO machine is with emergency stop button and XYZ axis limit switches.Machinable material: Wood、 plastic、 PCB、 PVC、 carbon fiber、 acrylic、 density board etc GRBL controller board Connection: USB (USB-CH340)Software: GRBL controller, UniversalGcodeSenderInput voltage:24VDCMaster chip: atmel 328P (arduino nano)Spindle drive chip: MOSFET (recommendation 24V, current : within 10ASpindle PWM speed: SupportSupport stepper motor: 12V, maximum current of 2A or less is recommended within 1.5A and additional heat. (Any stepper motor Nema17/Nema23)Power Interface: 5.5-2.5mm DC interfaceSupport 3-pins module: support Support oftware: GRBL controller,Candle, UniversalGcodeSenderInput voltage: 12-24VDCThe spindle supports 0-100% adjustable PWM power.Support limit switch, tool setting, steering gear, cooling fan and other functions.Support PWM / TTL signal control, power 0-100% adjustable!Increase the power button switchCancel the drive module,integrate the imported stepper motor drive,no need to worry about module damage. And integrated heat dissipation aluminum alloy.Add emergency stop ports & XYZ limit switches portsAdd offline recognition function, you can insert offline module and computer at the same time. The machine will automatically recognize whether it is controlled by the computer.Enhanced spindle drive.can support 20,000 rpm spindle.Add the fan port to force heat dissipation Add Offline controller Main Page Ctrl: Machine Control; File: Use the Gcode file; Press [Y+] [Y-] to select; Press[Ok] to Enter Control Page X± Y± Z±: Moving AxisOK/Spindle: Spindle ON/OFFExit/Step: Change Step/Exit (long press)How to increase the spindle power: After pressing the spindle button, press and hold the OK button and the Z+ button simultaneously to increase the speed.How to decrease the spindle: After pressing the spindle button, press and hold the OK button and the Z- button simultaneously to decrease the speed. File Page Common supported formats include nc. tex. tap.Press [Y+] [Y-] to select filePress [Ok] to EnterPress [Ok] to begin if you are readyNote:Long press [Exit] to stop machining Compared with the old version Add the function of X/Y/Z axis limit switches,optimized the XYZ limit port and the port connected to the device,making wiring and operation easier.After installing the limit switch, when the XYZ axis moves beyond the travel of the engraving machine, the limit switch will trigger the machine to automatically stop the movement.Add the function of emergency stop button,this function can be used when an emergency stop is required at work, making our work safer and more efficient.Add the power button switch and move the power switch button from the bottom to the side,simple operation,more safety in the process of using the machine. Advantage Add emergency stop button port, probe port and XYZ limit port.Add the outer casing: protect control board in transit,to avoid short circuit problem during use;Add the power button switch;Cancel the drive module,use integrated imported stepper motor drive,with short circuit protection,and integrated heat dissipation aluminum alloy;Add the fan port to force heat dissipation;Add offline recognition,can insert offline modules and computers at the same time.Offline will automati

Características

• Type: Upgraded CNC 3018-PRO with Offline Controller; We have added E-Stop button and XYZ limit switches; The two sides of the Y-axis have been replaced by orange electric wood resin boards,the sturdy outer frame is made of resin,the workbench is made of aluminum alloy,and the screw material is made of stainless steel,making the machine more lightweight,delicate and durable,and is highly favored by CNC beginners and enthusiasts
• With offline controller: You can operate this machine without connect to the computer; offline controller included a SD card reader to write into the root directory G-code files or NC file; Support manually adjust X, Y, Z axis location as engraving starting point,manually open or close spindle
• Parameters: Working area: 300x180x45mm / 11.8 x 7.1 x 1.8 inches;Frame size: 420x350x270mm / 16.53x13.78x10.63 inches; Spindle: 775 spindle motor 120W 12-36V,24V is 10000rpm; Stepper Motor: Nema17 stepper motor 1.33A,42x42x34mm,0.3N.m,43 oz-in; Computer System Requirements:Windows XP SP3,Win 7,Win 8,Win 10,Win 11 32/64 can be and Linux
• Instructions: Our parcel include a 4G USB flash drive,it include the detailed installation instructions,user manual and GRBL software; We also have detailed assembly and usage video tutorials, as well as strong after-sales technical support, so you don't have to worry about the assembly and use of the machine at all
• Specifications of GRBL Control Board: Added the outer casing,emergency stop button port,tool setting/probe port,X/Y/Z axis limit port and add the power button switch,with the fan to force heat dissipation,enhanced spindle drive,can support max 20000rpm spindle,and also can support 0.5W-20W 12V PWM/TTL engraver module
• Widely Applications: Can be engraved plastic, leather, acrylic, pvc, pcb, wood and the like material,also can work on soft metal like copper,brass,aluminum and other similar metal materials; If you change the spindle to a 12V 3-pins engraver module,then you can also use it to carve the kraft paper, wood, leather wallet and rubber etc
• Advantages of Upgraded Version: The machine has added an E-stop button;During the carving process,if there is an emergency situation,the user can press the button to stop the operation; Added limit switches for X/Y/Z axis,when the machine moves up and down or left and right, if it exceeds the travel range, it will trigger a stop,making the operation safer and more reliable
