Digital LED Tachometer RPM Speed Meter with Inductive Proximity Switch Sensor NPN DC 8-24V 40mA 10-9999RPM for Industrial Machinery Green

Descripción

Product description 4 Digital LED Tachometer RPM Speed Meter+Hall Proximity Switch Sensor ViaGasaFamido Package List: 1 x LED Tachometer 1 x Hall Proximity Switch 1 x Round Magnet 1 x Cable Specification: Item Type: Tachometer Operating Voltage: DC 8-24V, 40mA Display: 0.56inch Green LED, 4 Digit Reading Measuring Range: 10-9999RPM Measuring Accuracy: ±0.1%, Reading±1Digit Display Refresh Rate: >3 Times/Sec Overrange Display: Display "1" or "-1" in the First Digit Position, None in the Last Three Digit Positions Hall Proximity Switch Type: NPN NO Tachometer Size: 79x26x43mm / 3.11x1.02x1.69in Common errors in use Please note that the instrument only feeds back the detected correct working state, and will not process the data. The test data jumps too much. Please check whether the test object rotates at a constant speed and the installation is stable. Note: Please note that the new and old models are shipped randomly, and make sure you will not mind before ordering. Matters needing attention: 1. Connect the plug correctly according to the wiring diagram.2. Hall switch is NPN normally open, and the detection distance of Hall switch should be within 10mm. Hall switch is installed with a diameter of 12mm and a line length of less than 1m.3. Strong electromagnetic interference should be avoided. It is best to use shielded wire or twisted-pair wire for measuring wires.4. The input switch or circuit of the counter's counting signal and reset signal should be as close as possible to the terminal of the counter, and the signal line should be as short as possible.5. Avoid being in the same tube or twisted with other wires, such as high-voltage wires or power wires, so as to avoid unnecessary interference. If necessary, please use shielded wires, and the shielding layer is connected to the counting terminal "+".6. It is not recommended to use mechanical switches or micro-switches, because their service lives are relatively short and they are easy to count by mistake after a long time; When using mechanical switches or microswitches, please try to use better quality ones to avoid false counting. It is strongly recommended to use magnetic switches.

Características

• LCD Display: The digital tachometer has 0.56inch 4-digit LED screen display clear RPM readings in green. Which gives you a better visual experience and easier reading.
• Important Parameter: This is a digital tachometer with measuring range of 10-9999RPM, power supply is 8-24V, measuring accuracy is ±0.1%.
• Fully Equipped: This digital tachometer comes with 1 x 3 wire NPN hall proximity switch sensor, 1 x round magnet, 1 x cable. Its equipment is very complete.
• Impressive Features: This digital tachometer is characterized by high precision, , stable and This digital tachometer can be applicable to various applications of RPM speed measurement.
• Note: The Hall switch and the motor need to be fixed with brackets. The more stable the fixing, the more conducive to stable detection.
