Motor de ventilador YZF18-25 Motor de poste sombreado de 18 W para evaporador enfriador de condensador | Motor de ventilador de CA de entrada 120V 60Hz 1.01A 70W salida 18W para equipos de ventilación pequeños refrigerador congelador venta de bebidas

Descripción

Product description YZF18-25 YZF10-20 YZF6-13 AC Motor YZF18-25 Fan Motor 18W YZF10-20 Fan Motor 10W YZF6-13 Fan Motor 6W YZF18-25 Fan AC Motor YZF18-25 Fan AC Motor 120V 1.01A 60Hz 18W/70W 1550rpm YZF10-20 Fan AC Motor YZF10-20 Fan AC Motor 120V 0.8A 60Hz 1550rpm 10W/55W YZF6-13 Fan AC Motor YZF6-13 Fan AC Motor 120V 6W/33W 0.55A 60Hz 1550RPM YZF18-25 Certified by UL/CSA. All materials comply with the ROHS standards YZF10-20 Certified by UL/CSA. All materials comply with the ROHS standards YZF6-13 Certified by UL/CSA. All materials comply with the ROHS standards High compatibility The motor is compatible with most refrigeration equipment available on the market Condenser Motor for Refrigeration Equipment,Small Ventilation Equipment Radiator Evaporator Freezer Motor technical parameters product display The video showcases the product in use.The video guides you through product setup.The video compares multiple products.The video shows the product being unpacked. 360-degree display of fan motor products The tools needed are only a screwdriver and a wrench. The video showcases the product in use.The video guides you through product setup.The video compares multiple products.The video shows the product being unpacked. Fan Motor Installation Instruction Video Fan motor installation instruction video. The tools needed are only a screwdriver and a wrench

Características

• Single phase 4-pole shaded pole motor,120V 60HZ 1550r/min,Input power 70W, output power 18W, rated air volume 940m3/h，evaporative cooler motor rotation direction(CCW)1550 R ,No professional installation is required, nor any additional cost. This task can be easily accompl ，YZF18-25AC Fan Motor Can replace yzf10-20 and yzf6-13
• The AC Fan motor has a built-in thermal protector and the protection disconnection temperature is 257℉，vevor slush machine parts ，Applicable ambient temperature for the motor: -13°F to 122°F,used onsmall ventilation equipment, refrigeration equipment such as radiator evaporator for more than 10 years。
• AC motors can be used with a blade angle of 28° and a diameter of Φ200mm (8 inches). The yzf10-20 motor can be used with a blade angle of 28° and a diameter of Φ230mm (9 inches). The yzf18-25 can be used with a blade angle of 28° and a diameter of Φ254mm (10 inches). They can also be freely combined according to the power of the equipment and the installation environment
• condenser fan motor Sleeve bearings structure,the average service life of motors is over 20000 hours，his low-power old brand fan motor has an average service life of over 20,000 hours. Rated air volume: 940m3/h, 115V, 1550R. Rated voltage: 120 Volts, 60Hz. Different models, power output is the same: YZF18-25 fan motor. Current: 1.01A, Output power: 18W, Input power: 70W, 1.01A; YZF10-20 Input power: 55W, output power: 10W), 0.8A; YZF6-13 Input power: 33W, output power: 6W, 0.55A; Suitable for many brands of refrigeration equipment, with excellent compatibility. Since its sales in 2019, customers have reported that it works reliably and offers good value for the pric
• yzf18-25 fan motor Verified by extensive use, this product operates stably and is cost-effective. The refrigerator fan motor has UL/CSA certification number E224013. All materials comply with the ROHS standard, ensuring high stability and long service life. We offer a 2-year manufacturer warranty. In addition, each motor is equipped with a professional user manual and video installation guidance provided by senior engineers with years of refrigeration industry experience. Installation issues are easily resolved. Since its first launch in 2019, thanks to its stable quality and reasonable price, this motor has been well-received by users

Especificaciones
