X79 S7 Gaming Motherboard for Intel LGA 2011 Socket Xeon E5 Series CPUs, Support DDR3 RAM Max 256GB, NGFF/NVME M.2, SATA 3.0, PC Computer Server Mainboard

Descripción

Product description Frequently Asked Questions Computer won't start, fan doesn't spin, indicator lights are off Check CPU compatibility or damage; check motherboard and CPU power supplies; check power button cable; check power switch on; check power supply; disconnect graphics card, hard drive, USB devices, etc., then try powering on again; clear CMOS. The fan spins briefly and then immediately shuts off, or the computer repeatedly restarts Clear the CMOS; check CPU and memory compatibility or damage; disconnect the graphics card, hard drive, USB devices, etc., and then try powering on. The fan is spinning, but pressing the Caps Lock key on the keyboard doesn't activate the indicator lights Try clearing the CMOS; checking that the motherboard and CPU power supplies are properly connected; checking for CPU and memory compatibility issues or damage; and checking that the memory is installed correctly. The fan is spinning. Pressing the Caps Lock key on the keyboard illuminates the indicator light, but there is no display Check if the monitor is powered on or damaged; check if the display data cable is properly connected or damaged; check if the graphics card is working properly. Blue screen, system crash Check if the CPU cooling fan is spinning and if the cooling fan base is properly seated on the CPU; replace the CPU, memory, hard drive, operating system, and power supply.

Características

• LGA 2011 Socket: The X79 Server motherboard support Intel LGA2011 socket CPU processors (e.g. Intel Xeon E5 1620/1660/2603/2620/2667/2690, E5 1603 V2/ 2620 V2/26340 V2/2670 V2/2695 V2, etc.)
• Dual-channel DDR3: The Intel LGA 2011 gaming motherboard supports DDR3 Desktop/ECC/RECC memory up to 256GB (4*64GB), and supports 1066/1333/1600Mhz
• Stable Power Supply: 8-phase power supply, all-solid-state capacitor design, fine workmanship, professional stability. And the DDR3 mainboard is equipped with 24+8 pin power interface (please use a brand power supply of at least 500w)
• Rich Interfaces: The Micro ATX placa madre features RJ45 gigabit network interfaces, and the maximum network transmission rate can reach 1000bps/s. And with M.2 slots (support NVME SSD/NGFF SSD), PCIe 3.0 X16, PCIe 2.0 x1, SATA 3.0, SATA 2.0, USB 3.0, USB 2.0
• Excellent performance: The DDR3 computer motherboard uses Intel X79 chipset and 8-layer PCB material. And with Heat dissipation armor protection for strong heat dissipation, to ensure stable bus communication
• Package Lists: 1* X79 S7 mainboard, 1*SATA cable, 1*I/0 shield, 1*LGA2011 cooler bracket. IMPORTANT: The user manual for the motherboard is not included, Please ask us on Amazon to get the manual file if you need. And the motherboard does not include a CR2032 battery, please purchase one yourself
• Tips 1: If the white motherboard is DOA, cannot boot and has other problems, please let us know on Amazon so that we can help you. We recommend Driver Talent/DriveTheLife or Windows 10 system, which can help you solve all driver problems
• Tips 2: The graphics card boot mode of this motherboard is set by default to support only UEFI. It does not support old graphics cards in UEFI mode. Legacy (traditional) mode systems (ghost version systems, systems installed with USB flash drives) cannot enter the system. If you want to use old graphics cards or legacy systems, please enter the BIOS to change the graphics card boot mode to Legacy.
