5Pcs Pulse Trigger Switch Module DC Control MOSFET Optocoupler Electronic Switch Control Board DC 5 to 36V Input Controlled Voltage

Descripción

Product description Product Parameters Input Signal Voltage 3.3V - 24V Input Current 5mA Output Controlled Voltage 5V - 36V Output Current <5A (up to 20A with a heat sink MOSFET Type F5305S Input/Output Interface 7.62mm pitch terminal block Mounting Hole Diameter 3.8mm Dimension 46 x 25.5 x 14 mm Key Features High Reliability: Engineered for long-term stable performance.Low Power Consumption: Efficient operation with minimal energy usage.Easy Integration: Seamlessly integrates into existing systems, saving time and effort.Wide Application: Suitable for diverse projects including motor control, lighting systems, and industrial automation. Applications Motor speed controlLighting control systemsIndustrial automationDIY electronics projects

Características

• Highly Isolated and Universally Compatible: This optocoupler-based pulse trigger switch module provides complete electrical isolation between input and output, ensuring safe and reliable operation in sensitive electronic systems. It is compatible with a wide range of digital signals (high/low level), making it easy to connect to MCU ports, PLCs, and DC power supplies for seamless integration into your projects.
• Wide Input Voltage Range: Designed for versatility, this MOSFET control board supports input voltages from 3V to 24V with a low current draw of approximately 5mA, offering efficient performance with minimal energy loss. Perfect for applications such as motor speed control, LED lighting, and more.
• Powerful Output Control: The module can handle output voltages from 5V to 36V and currents up to 5A (with a heat sink, up to 20A), making it ideal for driving high-power devices. Built for long-term stability, it ensures consistent performance in industrial automation, robotics, and DIY electronics projects.
• Advanced PWM Control: Equipped with the F5305S power MOSFET, this optocoupler module delivers accurate and responsive PWM control, enabling precise motor speed regulation, dimming, and other advanced applications. Its fast response time and low latency make it a top choice for demanding environments.
• Versatile Use with Complete Kit: This package includes five isolated MOSFET pulse trigger switch modules, each designed for immediate use in motor control, lighting systems, and industrial automation. Whether you're working on a professional project or a personal build, this kit offers everything you need for reliable and flexible control solutions.
