U.S. Solid Motorized Ball Valve- 3/4" NSF Certified 304SS Ball Valve with Full Port, 9-24V AC/DC and 2 Wire Auto Return Setup

Descripción

Product description Motorized ball valves offer an energy-efficient alternative to solenoid valves, especially for prolonged positioning. They mainly consume energy during opening and closing, with negligible amounts once fully opened. This allows for permanent connection without the risk of overheating or burning out. Port Size 3/4" NPT (Full Port) Valve Material Stainless Steel Close/Open Time 3-5 Seconds Working Voltage 9-24V AC/DC Max Power 5 W Max Torque 2 N m Max. Pressure 145 PSI （1.0 Mpa） Temperature Range Medium Temp: 32℉ to 194℉; Ambient Temp.: 14℉ to 104℉ Applicable Medium Water Life Expectancy 80,000-100,000 Cycles Flow Aperture 0.79 inch (20 mm) Normally Open/Closed Normally Closed Auto Return YES Waterproof Rating IP65 Wiring 2 wire,auto return Seal PTFE U.S. Solid Motorized Ball Valve 3/4" SS Ball Valve with Full Port, 9-24V AC/DC and 2 Wire Auto Return This valve comes in stainless steel. It is 3/4” in diameter, and is full port. This means the diameter of the opening in the ball is a full 3/4”. If you are using this for a system where pressure is important, or with mixed materials, where restrictions on flow can lead to the separating of the material, a full-bore ball valve is your best option. These valves are not intended for situations where fast action closing or opening is needed, as they do take a few seconds to fully open and close. Wiring your new Motorized Ball Valve 2 Wire Auto Return DC: Connect the yellow wire to the negative pole(-). The valve will open when the red wire is connected to the positive pole(+), and close when the blue wire is connected to the positive pole(+). Disconnecting any wire will maintain the valve's current state. AC: Connect the yellow wire to any pole. The valve will open when the red wire is connected to the other pole, and close when the blue wire is connected to the other pole. Disconnecting any wire will maintain the valve's current state. Cherished by DIY Community, Approved by Engineers Meticulously tested and performance-rated parts ensure quality. With a lifespan of up to 100,000 cycles, the valve operates in 3-5 seconds; higher voltage enables quicker opening and closing. The robust 2Nm torque in the stem, often overlooked, is crucial for enduring serious torque without failure. Precision Threading How to Install the Motorized Ball Valve? This motorized ball valve features standard NPT threading, commonly used in U.S. piping. The tapered threading enhances connection sealing, requiring pipe thread tape for installation. Meticulously manufactured and tested, ensuring precise threading for straightforward installation. Apply pipe thread tape tightly to the male pipe end to facilitate a secure connection. Screw tightly into the valve to maintain a leak-free connection throughout its lifespan. What is the Waterproof Rating of this valve? The motor's housing is rated at IP65 for ingress protection. If permanently installed outdoors, it is recommended to place it under a shelter or in a protective box to prevent prolonged exposure to rain. For more details, please refer to Picture 1. What is the difference between N.C. (Normally Closed) and N.O. (Normally Open) ? In a N.C. valve, it's closed without power and opens when energized. Conversely, in a N.O. valve, it's open without power and closes when energized, blocking fluid or gas flow. For more details, please refer to Picture 2. What is the difference between Full Port and Standard Port? In a full port valve, the internal diameter of the valve is the same as the pipe it's connected to. In a standard port valve, the internal diameter of the valve is smaller than the pipe size. For more details, please refer to Picture 3. Can this be used for Drinking Water? YES. The motorized ball valve is made of lead-free stainless steel and is NSF certified. For auto return valves, what is the minimum On-Time required for electrical storage to enable closing when power off? To ensure automatic reset functionality when the power is disconnected, it is essential to power the device for approximately one minute to charge the capacitor in 2-wire auto return motorized ball valves. 3/4" Motorized Ball Valve USS-MSV00008 Add to Cart USS-MSV00002 Add to Cart USS-MSV00021 Add to Cart USS-MSV00023 Add to Cart USS-MSV00039 Add to Cart USS-MSV00072 Add to Cart USS-MSV00050 Add to Cart Customer Reviews 4.5 out of 5 stars 551 4.4 out of 5 stars 286 4.2 out of 5 stars 155 4.1 out of 5 stars 79 4.0 out of 5 stars 120 4.6 out of 5 stars 46 4.2 out of 5 stars 252 Price $57.19$57.19 $43.20$43.20 $40.39$40.39 $43.99$43.99 $43.10$43.10 $42.20$42.20 $58.59$58.59 Valve Material Stainless Steel Stainless Steel Brass Brass Stainless Steel Stainless Steel Brass Bore Type Full Port Full Port Standard Port Standard Port Full Port Full Port Standard Port Auto Return ✔ ✘ ✘ ✘ ✔ ✔ ✔ Working Voltage 9-24V AC/DC 9-24V AC/DC 9-24V DC 9-24V AC/DC 9-24V AC/DC 9-24V AC/DC 85-265V AC Wiring 2 wire,auto return 3 wire 2 wire,reverse polarity 5 wire 2 wi

Características

• NSF CERTIFIED 304 STAINLESS STEEL: The metal components are NSF Certified 304 stainless steel that resists corrosion and is safe for drinking water; a lead-free path for potable water and general fluid lines
• 2-WIRE AUTO RETURN NORMALLY CLOSED: A simple two-wire connection opens the valve when energized and automatically returns it to the normally closed position when power is removed; keep it powered to hold open
• 9-24 V AC/DC ACTUATION: Operates across the full 9 to 24 V AC/DC range and drives fully open or fully closed in 3 to 5 seconds; draws 5 W with 2 Nm of torque; low power draw after reaching position helps reduce heat buildup
• FULL PORT UNRESTRICTED FLOW: The full-port bore matches the 3/4 inch pipe with a 20 mm opening for full, unrestricted flow and minimal pressure drop, suited to water, air, gas, and oil lines in home and irrigation systems
• IP65 RATED AND DURABLE: The IP65 enclosure seals against dust and water spray from all directions; PTFE and silicone seats with an NPT thread deliver a rated service life of 80,000 to 100,000 cycles for years of reliable use
